Utility Panels
OVERVIEW:
No matter what your animal containment needs are, OK Brand has the solution. These utility fence panels have multiple uses on farms and residences. All panels are manufactured using the galvanized-before-welding process, which gives a smooth finish to each line wire and eliminates sharp burrs. A wide variety of spacing configurations, along with several lengths in either 4-gauge or 6-gauge, makes these panels extremely versatile for many applications, including hog pens, hog traps, dog pens, and many other farm and residential uses.
SPECIFICATIONS:
4×4 UTILITY PANELS – 4- GAUGE | ||||||||
ITEM # | PRODUCT | WIRE GAUGE | SPACING | HEIGHT | LENGTH | APPROX. WEIGHT | PANELS PER BUNDLE | TAG COLOR |
1240-0 | 4′ x 16′ | 4 | 4″ x 4″ | 4′ | 16′ | 55 lbs. | 50 | |
1250-0 | 4′ x 20′ | 4 | 4″ x 4″ | 4′ | 20′ | 68 lbs. | 50 | |
1280-0 | 5′ x 16′ | 4 | 4″ x 4″ | 5′ | 16′ | 68 lbs. | 50 | |
1290-0 | 5′ x 20′ | 4 | 4″ x 4″ | 5′ | 20′ | 85 lbs. | 50 | |
1310-0 | 6′ x 20′ | 4 | 4″ x 4″ | 6′ | 20′ | 101 lbs. | 50 |
4×8 UTILITY PANELS – 4- GAUGE | ||||||||
ITEM # | PRODUCT | WIRE GAUGE | SPACING | HEIGHT | LENGTH | APPROX. WEIGHT | PANELS PER BUNDLE | TAG COLOR |
1990-0 | 5′ x 20′ | 4 | 4″ x 8″ | 5′ | 20′ | 64 lbs. | 50 |
6×6 UTILITY PANELS – 4- GAUGE | ||||||||
ITEM # | PRODUCT | WIRE GAUGE | SPACING | HEIGHT | LENGTH | APPROX. WEIGHT | PANELS PER BUNDLE | TAG COLOR |
2100-0 | 4′ x 20′ | 4 | 6″ x 6″ | 4′ | 20′ | 46 lbs. | 50 | |
2120-0 | 5′ x 20′ | 4 | 6″ x 6″ | 5′ | 20′ | 58 lbs. | 50 | |
2140-0 | 6′ x 20′ | 4 | 6″ x 6″ | 6′ | 20′ | 69 lbs. | 50 |
2×2 UTILITY PANELS – 6- GAUGE | ||||||||
ITEM # | PRODUCT | WIRE GAUGE | SPACING | HEIGHT | LENGTH | APPROX. WEIGHT | PANELS PER BUNDLE | TAG COLOR |
0893-95 | 4′ x 12′ | 6 | 2″ x 2″ | 4′ | 12′ | 57 lbs. | 25 | |
0894-0 | 4′ x 16′ | 6 | 2″ x 2″ | 4′ | 16′ | 75 lbs. | 25 | |
0894-05 | 5′ x 12′ | 6 | 2″ x 2″ | 5′ | 12′ | 71 lbs. | 25 | |
0894-1 | 5′ x 16′ | 6 | 2″ x 2″ | 5′ | 16′ | 93 lbs. | 25 |
4×4 UTILITY PANELS – 6- GAUGE | ||||||||
ITEM # | PRODUCT | WIRE GAUGE | SPACING | HEIGHT | LENGTH | APPROX. WEIGHT | PANELS PER BUNDLE | TAG COLOR |
1699-6 | 3′ x 16′ | 6 | 4″ x 4″ | 3′ | 16′ | 30 lbs. | 50 | |
1700-0 | 3′ x 20′ | 6 | 4″ x 4″ | 3′ | 20′ | 38 lbs. | 50 | |
1740-0 | 4′ x 16′ | 6 | 4″ x 4″ | 4′ | 16′ | 40 lbs. | 50 | |
1750-0 | 4′ x 20′ | 6 | 4″ x 4″ | 4′ | 20′ | 50 lbs. | 50 | |
1760-0 | 5′ x 12′ | 6 | 4″ x 4″ | 5′ | 12′ | 37 lbs. | 50 | |
1770-0 | 5′ x 16′ | 6 | 4″ x 4″ | 5′ | 16′ | 49 lbs. | 50 | |
1780-0 | 5′ x 20′ | 6 | 4″ x 4″ | 5′ | 20′ | 62 lbs. | 50 | |
1790-0 | 6′ x 20′ | 6 | 4″ x 4″ | 6′ | 20′ | 74 lbs. | 50 | |
1820-0 | 8′ x 16′ | 6 | 4″ x 4″ | 8′ | 16′ | 79 lbs. | 50 | |
1840-1 | 8′ x 20′ | 6 | 4″ x 4″ | 8′ | 20′ | 95 lbs. | 25 |
6×6 UTILITY PANELS – 6- GAUGE | ||||||||
ITEM # | PRODUCT | WIRE GAUGE | SPACING | HEIGHT | LENGTH | APPROX. WEIGHT | PANELS PER BUNDLE | TAG COLOR |
2190-0 | 5′ x 20′ | 6 | 6″ x 6″ | 5′ | 20′ | 42 lbs. | 50 |
RECOMMENDED FOR:
